IN STOCK
The Add-A-Step is the easiest way to increase the height of your SMARTSTEP® GLOWSTEP REVOLUTION® steps. You can easily add or remove steps because the RV step is bushing bolted. It can be as short as two steps or as high as six steps.
The A8101B is designed for the SMARTSTEP® GLOWSTEP REVOLUTION® steps that feature a step width (not including outside links) of 19.5-inches and a bracket of 25-inches.
This kit ships complete. Kit includes bolt/accessory kits
Do you find that at certain campgrounds that are incredibly angled or uneven that your steps would be absolutely perfect if there was just one more step? Torklift has your back with the Add-A-Step accessory kit. Easy to install, the Add-A-Step still has the same original design as the SMARTSTEP® GLOWSTEP REVOLUTION® steps, it just gives you the ability to add an extra step when you need it! The multi-link hinge design of these RV steps accommodates any space constraint, so it doesn’t matter how close you park to structures, trees, service bays or inside of a storage facility – you’re still able to use these trailer steps.
To maximize a lifetime of smooth action and ease of use, the RV steps are assembled carefully by hand and adjusted to precise torque. The unique bushing bearing design is used on each side of every hinge point on the steps, preventing the step hinges from coming loose over time. The bushings act as a bearing surface that can handle significant tension without over-stiffening the step configuration, a common problem found on rusting factory steps. Due to these features, Torklift's GlowStep line of RV steps guarantee longevity, durability and quality.
*Accessory only, steps and bracket sold separately. To purchase your SMARTSTEP® GLOWSTEP REVOLUTION® steps, visit here.
Features of the SMARTSTEP® GLOWSTEP REVOLUTION® Add-A-Step Include:
|
GLOWSTEP REVOLUTION®
|
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| Description / Part Number | Width between factory mounting brackets (A) | Height from top of step opening to ground (B) | Height from top of step opening to bottom of stored steps (C) | Step Tread Depth x Width | Weight Capacity | Notes | |||
|
Add-A-Step (for A8002-A8005) |
27.5" | N/A | N/A | N/A | N/A | ††† | |||
| 2 Step Part Number: A8002 |
27.5" | 18.5" to 24" | 11.5" to 12.5" | 8"d x 22.5"w | 375lbs |
††† | |||
| 3 Step Part Number: A8003 |
27.5" | 25.5" to 32" | 13.75" to 14.75" | 8"d x 22.5"w | 375lbs |
††† | |||
| 4 Step Part Number: A8004 |
27.5" | 32.5" to 40" | 16" to 17" | 8"d x 22.5"w | 375lbs |
††† | |||
| 5 Step Part Number: A8005 |
27.5" | 39.5" to 48" | 18.25" to 19.25" | 8"d x 22.5"w | 325lbs |
††† | |||
| 6 Step Part Number: A8006 |
27.5" | 46.5" to 56" | 20.5" to 21.5" | 8"d x 22.5"w | 325lbs |
††† |
|||
| Add-A-Step (For A8102-A8105) Part Number: A8101B | 25" | N/A | N/A | N/A | N/A | ††† | |||
| 2 Step Part Number: A8102 |
25-25.5" | 18.5" to 24" | 11.5" to 12.5" | 8"d x 22.5"w | 375lbs | ††† | |||
| 3 Step Part Number: A8103 |
25-25.5" | 25.5" to 32" | 13.75" to 14.75" | 8"d x 22.5"w | 375lbs | ††† | |||
| 4 Step Part Number: A8104 |
25-25.5" | 32.5" to 40" | 16" to 17" | 8"d x 22.5"w | 375lbs | ††† | |||
| 5 Step Part Number: A8105 |
25-25.5" | 39.5" to 48" | 18.25" to 19.25" | 8"d x 22.5"w | 325lbs | ††† | |||
| 6 Step Part Number: A8106 |
25-25.5" | 46.5" to 56" | 20.5" to 21.5" | 8"d x 22.5"w | 325lbs | ††† | |||
|
† Do not use Add-A-Step Kit to convert a six-step to a seven-step. †† All Terrain Landing Gear not included. ††† With use of Torklift GlowGuide. Otherwise 2-4step MAX CAP 350lbs / 5-6 MAX CAP 300lbs. * The GLOWSTEP REVOLUTION® is available from two to six steps. The six step is specifically available for side-entry truck campers that have a larger opening to the ground. Most travel trailers, toy haulers and 5th wheels will only require two to five step applications. **GlowGuide handrail works with the 6-step GLOWSTEP REVOLUTION® but must be installed on the second step from the bottom. |
|||||||||
